Ting Flanges, Manila’s leading manufacturer and supplier, is renowned for making high-quality BS 10 Table F Flanges according to British Standard specifications. Engineered for strength, precision, and performance, these flanges are suitable for moderate pressure and temperature applications. Ting Flanges employs the latest manufacturing techniques and rigorous quality assurance to guarantee that each product is of international standards and customer needs. With emphasis on dependability and customer satisfaction, the company continues to deliver reliable flange solutions to different industries in the Philippines and globally.
BS 10 Table F Flanges are usually constructed from carbon steel, stainless steel, or mild steel, offering a combination of strength, durability, and corrosion resistance. They show good mechanical properties of moderate tensile strength, toughness, and excellent machinability. These flanges are capable of enduring medium-pressure systems without compromising structural integrity. Their make ensures weldability and fabrication ease, meaning they can operate successfully under moderate thermal and mechanical loads. Such strength, ductility, and resistance to corrosion make them ideal for many industrial uses.
Ting Flanges, a leading supplier in Manila, Philippines, offers an extensive selection of BS 10 Table F Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size | (1/2″) To (48″) |
|---|---|
| Size Of Bore Diameter Flange | NPS ≤ 10 |
| Standard Dimensions | EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, API7S-43, ANSI/ASME B16.5, API7S-15, MSS S44, IS 2062, ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, ISO70051, API. |
| Minimum Pressure | 150# To 2500# |
| Flange Face Type Manufacturer | Raised Face, Groove And Small Tongue Groove, RTJ, Flat Face, Large Tongue & Large Male-Female And Small Male-Female, Lap-Joint Face. |
| Top Six Type Of Flange | Threaded Flange, Lap Joint Flange, Socket-Weld Flange, Blind Flange, Slip-On Flange, Weld Neck Flange |
| Standard Materials | Duplex Steel & Super Duplex Steel, Copper Nickel, Inconel, Mild Steel, Stainless Steel, Hastelloy, Alloy Steel, Carbon Steel. |
| Thickness Length | NPS ≤ 18 |
| Manufacturing Process | Forged/ Machined/ Heat Treated |
| Other Type Of Flange | Forged/ Plate/ Threaded |
| Normal Pipe Size | A | D | L | K | C | B | H1 | H2 | N1 | N2 | R1 | R2 | HOLES | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | Millimeter | |||||||||||||
| ½” | 15 | 21.3 | 95.3 | 14.5 | 66.8 | 6.4 | 22.4 | 9.5 | 22.2 | 27.0 | 33.3 | 6.4 | 1.6 | 4 |
| ¾” | 20 | 26.7 | 101.6 | 14.5 | 73.2 | 6.4 | 27.7 | 11.1 | 22.2 | 33.3 | 38.1 | 6.4 | 1.6 | 4 |
| 1″ | 25 | 33.5 | 114.3 | 14.5 | 82.6 | 7.2 | 34.6 | 11.1 | 22.2 | 42.9 | 47.6 | 6.4 | 1.6 | 4 |
| 1 ¼” | 32 | 42.2 | 120.7 | 14.5 | 87.4 | 7.9 | 43.2 | 11.1 | 25.4 | 49.2 | 55.6 | 6.4 | 1.6 | 4 |
| 1 ½” | 40 | 48.3 | 133.4 | 14.5 | 98.6 | 8.7 | 49.5 | 12.7 | 28.6 | 58.7 | 61.9 | 6.4 | 1.6 | 4 |
| 2″ | 50 | 60.5 | 152.4 | 17.5 | 114.3 | 9.5 | 62.0 | 12.7 | 28.6 | 69.9 | 74.6 | 6.4 | 1.6 | 4 |
| 2 ½” | 65 | 73.2 | 165.1 | 17.5 | 127.0 | 10.3 | 74.7 | 15.9 | 31.8 | 82.6 | 90.5 | 6.4 | 1.6 | 4 |
| 3″ | 80 | 88.9 | 184.2 | 17.5 | 146.1 | 11.1 | 90.7 | 15.9 | 34.9 | 101.6 | 106.4 | 6.4 | 1.6 | 4 |
| 3 ½” | 88 | 101.6 | 203.2 | 17.5 | 165.1 | 11.9 | 103.4 | 17.5 | 34.9 | 114.3 | 119.1 | 6.4 | 1.6 | 4 |
| 4″ | 100 | 114.3 | 215.9 | 17.5 | 177.8 | 12.7 | 116.1 | 19.1 | 41.3 | 130.2 | 133.4 | 9.5 | 3.2 | 4 |
| 5″ | 125 | 141.2 | 254.0 | 17.5 | 209.6 | 14.3 | 143.8 | 19.1 | 44.5 | 152.4 | 160.3 | 9.5 | 3.2 | 8 |
| 6″ | 150 | 168.4 | 279.4 | 17.5 | 235.0 | 17.5 | 171.7 | 19.1 | 47.6 | 184.2 | 185.7 | 9.5 | 3.2 | 8 |
| 8″ | 200 | 219.2 | 336.6 | 17.5 | 292.1 | 19.1 | 221.5 | 22.2 | 50.8 | 241.3 | 241.3 | 9.5 | 3.2 | 8 |
| 10″ | 250 | 273.1 | 406.4 | 22.2 | 355.6 | 22.2 | 276.4 | 27.0 | 63.5 | 292.1 | 298.5 | 9.5 | 3.2 | 8 |
| Standard | Class | Diameter | Bolt Circle Diameter | Number of Bolts | Bolt Size | Diameter of Bolt Hole |
| AS4087 Flanges | PN14 Flanges | 95 | 67 | 4 | M12 | 14 |
| AS 2129 Flange | Table C Flanges | 95 | 67 | 4 | 13 | 14 |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table E Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table H Flanges | 114 | 83 | 4 | 16 | 17 | |
| Table J Flanges | 114 | 83 | 4 | 16 | 17 | |
| ANSI B16.5 Flanges | ANSI 150 Flanges | 89 | 60 | 4 | 13 | 16 |
| ANSI 300 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 600 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 900 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ANSI 1500 Flanges | 121 | 83 | 4 | 19 | 22 | |
| BS 10 (DIN) Flange | PN6 Flanges | 80 | 55 | 4 | M10 | 11 |
| PN10 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN16 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN20 Flanges | 90 | 60.5 | 4 | M14 | 16 | |
| PN25 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN40 Flanges | 95 | 65 | 4 | M12 | 14 |
BS 10 Table F Flanges are used in various industries like water treatment, plumbing, shipbuilding, oil and gas, and general engineering. They are best used to connect pipelines, valves, and other equipment that work under moderate pressure conditions. They are often used in low-pressure steam, water, and air services, fire protection systems, and HVAC installations. Their specific dimensions and leak-proof sealing provide safe and leak-free joints. BS 10 Table F Flanges provide a cost-effective and long-lasting solution for varied piping systems with required uniform performance and easy maintenance.
Yes, we offer custom sizes for BS 10 Table F Flanges to meet specific project needs. Our team at Ting Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@tingflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
