Ting Flanges, located in Manila, Philippines, stands out as a top-notch manufacturer and supplier of high-quality industrial flanges, with a special focus on ANSI B16.47 Series B Flanges. Renowned for their precision engineering and durability, Ting Flanges adheres strictly to international standards, ensuring that they deliver reliable piping components for large-diameter and high-pressure systems. Their ANSI B16.47 Series B Flanges are crafted to guarantee excellent performance, tight seals, and hassle-free installation across a variety of industrial applications. With a strong commitment to quality assurance, customer satisfaction, and timely delivery, Ting Flanges has earned a solid reputation both in the Philippines and around the globe in the flange manufacturing sector.
ANSI B16.47 Series B flanges are usually manufactured using carbon steel, stainless steel, or alloy steel, providing high strength and durability. The material contains constituents such as carbon (0.25-0.30%), manganese (0.60-0.90%), and chromium (up to 2%), based on the grade of the material. The flanges are used to provide resistance to high pressure and temperature conditions. The mechanical properties are tensile strength between 70 to 100 ksi (485 to 690 MPa), yield strength between 30 to 60 ksi (205 to 415 MPa), and elongation up to 20%, providing long-term and consistent performance in a range of industrial applications.
The ANSI B16.47 Series B Flanges from Ting Flanges are made from top-quality materials like carbon steel, stainless steel, and alloy steel, which provide exceptional mechanical strength and resistance to corrosion. These flanges typically boast tensile strengths between 60,000 and 100,000 psi, with yield strengths ranging from 30,000 to 60,000 psi, depending on the specific grade. Each flange undergoes precise machining and rigorous testing for dimensional accuracy and surface finish, ensuring leak-proof connections and durability even in tough conditions. They are perfect for high-pressure and high-temperature applications that demand reliability and a long service life.
| Size Range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
|---|---|
| DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Main Types | Threaded / Forged / Plate /Screwed |
| Flange supporting material | Ring Joint, Gasket, Flange Bolts |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Most Common Types |
|
| Production technique |
|
| Connect Type/ Flange Face Type | Ring Type Joint (RTJ), Raised Face (RF),Large Male-Female (LMF), Flat Face (FF),Small Male-Female (SMF), Lap-Joint Face (LJF), Large Tongue & Groove, Small Tongue, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2″) to 200 NB (8″) Equal and Reducing Configurations Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Bending machine, Press machine, electric bevelling machine, Pushing Machine, Sand-blasting machine etc |
| Origin | Indian / West Europe / Japan / USA / Korean |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
|
ASME B16.47 Series B Slip On Flange Class 150 LBS Dimensions
|
|||||||||
|
NPS |
A |
B |
I |
Holes |
C |
D |
F |
G |
Weight |
|
22″ |
750 |
563.6 |
35 |
20 |
46 |
80 |
610 |
641 |
72.66 |
|
26″ |
870 |
665.2 |
35 |
24 |
68.5 |
90 |
724 |
749 |
120.47 |
|
28″ |
925 |
716 |
35 |
28 |
71.5 |
95 |
781 |
800 |
136.16 |
|
30″ |
985 |
766.8 |
35 |
28 |
74.5 |
100 |
832 |
857 |
161.04 |
|
32″ |
1060 |
817.6 |
41 |
28 |
81 |
106 |
889 |
914 |
205.07 |
|
34″ |
1110 |
868.4 |
41 |
32 |
82.5 |
110 |
940 |
965 |
216.76 |
|
36″ |
1170 |
919.2 |
41 |
32 |
90.5 |
120 |
997 |
1022 |
265 |
|
38″ |
1240 |
970 |
41 |
32 |
87.4 |
120 |
1060 |
1073 |
297.15 |
|
40″ |
1290 |
1020 |
41 |
36 |
90.5 |
125 |
1111 |
1124 |
319.65 |
|
42″ |
1345 |
1071.6 |
41 |
36 |
97 |
130 |
1168 |
1194 |
363.84 |
|
44″ |
1405 |
1122.4 |
41 |
40 |
102 |
136 |
1219 |
1245 |
414.1 |
|
46″ |
1455 |
1173.2 |
41 |
40 |
103 |
144 |
1270 |
1295 |
437 |
|
48″ |
1510 |
1224 |
41 |
44 |
108 |
150 |
1327 |
1359 |
484.52 |
|
50″ |
1570 |
1274.8 |
48 |
44 |
111 |
160 |
1378 |
1410 |
521.23 |
|
52″ |
1625 |
1325.6 |
48 |
44 |
116 |
170 |
1435 |
1460 |
581.51 |
|
54″ |
1685 |
1376.4 |
48 |
44 |
121 |
178 |
1492 |
1511 |
652.63 |
|
56″ |
1745 |
1427.2 |
48 |
48 |
124 |
188 |
1540 |
1575 |
713.31 |
|
58″ |
1805 |
1478 |
48 |
129 |
195 |
1590 |
1626 |
799.81 |
|
|
60″ |
1855 |
1528.8 |
48 |
52 |
132 |
200 |
1657 |
1676 |
836.15 |
|
ASME B16.47 Series B Slip On Flange Class 300 LBS Dimensions |
|||||||||
| NPS | A | B | I | Holes | C | D | F | G | Weight |
| 22″ | 840 | 563.6 | 41 | 24 | 66.5 | 100 | 640 | 641 | 159 |
| 26″ | 970 | 665.2 | 44 | 28 | 79.5 | 130 | 720 | 749 | 238.15 |
| 28″ | 1035 | 716 | 44 | 28 | 85.5 | 147 | 775 | 800 | 295.5 |
| 30″ | 1090 | 766.8 | 48 | 28 | 92 | 160 | 825 | 857 | 338.8 |
| 32″ | 1150 | 817.6 | 51 | 28 | 98.5 | 170 | 880 | 914 | 395.57 |
| 34″ | 1205 | 868.4 | 51 | 28 | 102 | 180 | 935 | 965 | 446.43 |
| 36″ | 1270 | 919.2 | 54 | 32 | 105 | 190 | 990 | 1022 | 502.9 |
| 38″ | 1170 | 970 | 41 | 32 | 108 | 140 | 995 | 1029 | 256.33 |
| 40″ | 1240 | 1020 | 44 | 32 | 114 | 150 | 1050 | 1086 | 316.78 |
| 42″ | 1290 | 1071.6 | 44 | 32 | 119 | 156 | 1100 | 1137 | 343.98 |
| 44″ | 1355 | 1122.4 | 48 | 32 | 124 | 160 | 1150 | 1194 | 394.78 |
| 46″ | 1415 | 1173.2 | 51 | 28 | 129 | 170 | 1205 | 1245 | 455.19 |
| 48″ | 1465 | 1224 | 51 | 32 | 133 | 180 | 1255 | 1314 | 482.1 |
| 50″ | 1530 | 1274.8 | 54 | 32 | 140 | 190 | 1305 | 1359 | 557.35 |
| 52″ | 1580 | 1325.6 | 54 | 32 | 144 | 198 | 1355 | 1410 | 595.56 |
| 54″ | 1660 | 1376.4 | 60 | 28 | 152 | 210 | 1410 | 1467 | 741.05 |
| 56″ | 1710 | 1427.2 | 60 | 28 | 154 | 220 | 1465 | 1518 | 786.03 |
| 58″ | 1760 | 1478 | 60 | 32 | 159 | 228 | 1515 | 1575 | 824.35 |
| 60″ | 1810 | 1528.8 | 60 | 32 | 164 | 235 | 1585 | 1620 | 904.14 |
ANSI B16.47 Series B flanges are typically made of carbon steel, stainless steel, or alloy steel, which are very strong and durable. The material has elements like carbon (0.25-0.30%), manganese (0.60-0.90%), and chromium (up to 2%), depending on the grade of the material.These flanges can be utilized for high pressure and temperature conditions. The mechanical properties include tensile strength ranging from 70 to 100 ksi (485 to 690 MPa), yield strength ranging from 30 to 60 ksi (205 to 415 MPa), and elongation up to 20%, showing long-lasting and stable performance in various industrial industries.
Ting Flanges’ ANSI B16.47 Series B Flanges find extensive use in various industries, including oil and gas, petrochemicals, power generation, shipbuilding, and water treatment. Designed specifically for large-diameter pipelines, these flanges provide secure and efficient connections for systems that transport corrosive or high-pressure fluids. Their robust design guarantees superior sealing capabilities and long-lasting performance, even under extreme conditions. With a reputation for quality, precision, and durability, Ting Flanges’ ANSI B16.47 Series B Flanges offer reliable solutions for complex industrial piping networks worldwide.
